PMI-T3 CNC Automatic Double Head Miter Saw

Ideal for Applications in the Following Industries: Aerospace Aluminum Extruders Automotive Tier 1/2/3 suppliers Awnings and Storefronts Boat Docks Boat Manufacturers Curtainwall and Architectural Glass Door and Windows Furniture and Office Equipment Lighting – Architectural Medical Metal Service Centers Public and Stadium Seating RV Industry Solar Panels Tradeshow displays Trailer Industry – Recreational and Commercial Weapon, Gun, and Accessories Manufacturing The PMI-T3 CNC Automatic Double Head Miter Saw is built and designed to cut aluminum extrusions, profiles, and other non-ferrous materials (copper, brass, plastics). Standard Features & Equipment: Fully Automatic Operation One Saw Head is Fixed and the other is Moveable 5 HP Saw Motors (2) Saw Heads are CrossCut Design Servo Controlled, Powered Saw Heads – Tilt left and right 45 degrees tilt inwards 67.5 degrees tilt outwards Moveable Saw Head – Servo Controlled Working Lengths Available 177” or 256” Touchscreen Control 2800 RPM Saw Blade Speed Full Control of the Feed Rate – Air over Oil Feed System Vertical and Horizontal Clamping Adjustable Clamping Pressure 20” Diameter Saw Blades (2) 14” Maximum Sawing Height (at 90 degrees with 20” diameter saw blade) 6” Maximum Sawing Width (at 90 degrees with 20” diameter saw blade) Cut Chart:
