WaterTech Nova
WaterTech Nova
orCall 804.598.1780
Description
Main Features Dual drive brushless motors and gantry control Rack and pinion drive system Linear guides on the longitudinal axis 2 linear guides on transverse beam Self lubrication system for all guides Bellows protection on all axis, including double bellows protection on longitudinal axis, inner bellows covers linear guideways, and external bellows covers internal bellows Stainless steel water and abrasive tank Pressurized two-stage abrasive metering system Water table tank with manual water level controls Ready for future installation of an abrasive removal system Cutting table parameters with quality selections from 1 to 5
Specifications
| Manufacturer | Soitaab |
| Condition | New |
| Working area | 5ft. x 10ft. up to 10ft. x 40ft. |
| Motors (x, y, z) | Brushless |
| Driver (x, y, z) | Digital |
| Positioning speed | 1575 ipm (40 m/min) |
| Positioning accuracy | + - .004 in (+ - 0,1 mm/m) |
| Repeatability | +- .002 in (+ - 0,05 mm/m) |
| CNC | Soitaab CNC |
| Monitor | 15 in LCD touch screen |
| Data communication | USB - Ethernet - LAN |
| Cutting technologies | Water-jet with abrasive |
| Carriage stroke (z) | 8 in (optional 12 in) 200 mm (optional 300 mm) |
